MAIN FABRICATON ITEMS IN
           MARMARAY BC1 PROJECT

           1.095         meters NATM tunnel                      48.500        ceramic / tile / artificial marble
           12.500        meters infrastructure transmission      145.500       tons of iron
           22.800        meters of bored piles                   93.250        meters anchor
           24.500        m2 diaphragm wall                       764.000       m3 of excavation
           835.000       m3 of concrete                          144.617       m2 of filling
           35.000        m rail pad tunnel backfill concrete     10.000        m2 of wall
           45.700        m2 painting                             850           meters of pipes deplacement
           43.200        m2 of plaster                           56.000        m of rail
